Gate Valve with Electric Actuator

Overview

A Gate Valve with Electric Actuator is a type of valve used to control the flow of fluids in pipelines. The gate valve operates by raising or lowering a gate to either allow or block flow. When combined with an electric actuator, it allows for automatic control and precise operation, making it ideal for applications where remote or automated operation is required.

Specifications

Yaxing Valve’s Gate Valve with Electric Actuator comes with a wide range of specifications to meet various industry requirements. Here are the key specifications:

  ● Nominal Size: 2” to 48” (DN50 to DN1200)

  ● Pressure Rating: Class 150 to Class 2500

  ● Temperature Range: -20°F to 650°F (-29°C to 343°C)

  ● Body Material: Carbon Steel, Stainless Steel, Alloy Steel

  ● Actuator Type: Electric, Fail-Safe (Optional)

  ● Power Supply: 110V, 220V, 380V AC or DC (Customizable)

  ● Seal Type: Soft Seal, Metal-to-Metal Seal

  ● Connection Type: Flanged, Butt Weld, Threaded

  ● End Connection Standard: ANSI, API, DIN, JIS

  ● Actuation Speed: Customizable based on application

Key Features

  ● Electric Actuation for Precision Control: The electric actuator provides precise and reliable operation, ensuring consistent performance over time.

  ● Reliable Seal Design: Yaxing Valve’s Electric Gate Valves feature high-quality sealing materials that ensure leak-tight performance, even in high-pressure and high-temperature conditions. The soft-seal and metal-to-metal seal options provide flexibility depending on the application.

  ● Durability and Robustness: Constructed from high-quality materials such as carbon steel and stainless steel, our gate valves are designed for long-lasting performance in a wide range of industrial environments.

  ● Fail-Safe Functionality: Many of our electric actuators are designed with fail-safe capabilities, ensuring that the valve returns to a safe position in the event of power failure.

  ● Corrosion Resistance: Yaxing’s Gate Valves with Electric Actuators are equipped with corrosion-resistant coatings, making them suitable for applications involving aggressive chemicals, water treatment, and other corrosive fluids.

Maintenance & Care

While Yaxing Valve’s Gate Valves with Electric Actuators are designed to require minimal maintenance, proper upkeep is essential to ensure long-term performance. Here are a few essential maintenance tips:

  ● Regular Inspections: Perform regular visual inspections to ensure the valve and actuator are free from dirt, corrosion, or debris. Check the actuator for any signs of wear or malfunction, particularly the electrical connections and wiring.

  ● Lubrication: Ensure that the valve stem and actuator are adequately lubricated. Over time, lubrication can degrade, leading to increased wear on moving parts. Regular lubrication helps maintain smooth operation and extends the life of the valve.

  ● Check for Leaks: Periodically check for any leaks around the valve seal, actuator, and piping connections. Any signs of leakage should be addressed immediately to prevent system inefficiencies or failures.

  ● Actuator Calibration: Electric actuators may need periodic calibration to maintain optimal performance. Ensure that the actuator is calibrated according to manufacturer specifications to prevent inaccuracies in valve position.

  ● Electrical Check: Inspect electrical components for signs of wear or damage. Ensure that the wiring is properly insulated and that the electrical connections are secure to avoid operational failures.
